Product Description
General Information
|
Field |
Details |
|---|---|
|
Manufacturer |
ABB |
|
Product ID |
57120001-FG |
|
ABB Type Designation |
DSAO 130 |
|
Catalog Description |
DSAO 130 Analog Output Unit 16 Ch |
|
Long Description |
DSAO 130 Analog Output Unit with 16 Channels (0–10 V, 0–20 mA, Accuracy: 0.4%). Only available as spare for Safeguard safety controllers. Hardware license number required when ordering. For other controllers, use revitalized version DSAO 130A (3BSE018294R1) with DSTA 181 (3BSE018312R1). See StepUp offer STU3BSE077320R1. |
|
Exchange Number |
EXC57120001-FG |
|
Medium Description |
Analog Output Board |
|
Product Type |
I-O_Module |
Technical Information
|
Field |
Details |
|---|---|
|
Number of Channels |
16 |
|
Output Range |
0–10 V, 0–20 mA |
|
Accuracy |
±0.4% |
|
Availability |
Spare part for Safeguard safety controllers only |
|
Revitalized Alternative |
DSAO 130A (3BSE018294R1) + DSTA 181 (3BSE018312R1) |
|
License Requirement |
HW license number must be specified when ordering |
Ordering Information
|
Field |
Details |
|---|---|
|
HS Code |
853890 |
|
Customs Tariff Number |
85389091 |
Dimensions and Weight
|
Field |
Details |
|---|---|
|
Product Net Depth / Length |
324 mm |
|
Product Net Height |
18 mm |
|
Product Net Width |
225 mm |
|
Product Net Weight |
0.45 kg |
Environmental Compliance
|
Field |
Details |
|---|---|
|
RoHS Compliance |
Exempted under EU Directive 2011/65/EU, Article 2(4)(c), (e), (f), and (j) (Ref: 3BSE088609 – EU Declaration of Conformity) |
|
WEEE Category |
5. Small Equipment (No external dimension more than 50 cm) |
|
Number of Batteries |
0 |
|
SCIP Number |
c2c0231e-fa96-41fa-ad22-916f994abf20 (Sweden) |
Product Hierarchy
-
Products › Control System Products › I/O Products › S100 I/O › S100 I/O - Modules › DSAO 130 Analog Outputs
-
Products › Control Systems › Safety Systems › Safeguard › Safeguard 400 Series › Safeguard 400 1.6 › I/O Modules
-
Parts & Services › Control Systems › 800xA › I/Os › S100 I/O › I/O Modules
-
Parts & Services › Control Systems › Advant OCS with Master SW › Controllers › MasterPiece 200 and 200/1 › I/O Modules
-
Parts & Services › Control Systems › Advant OCS with MOD 300 SW › I/Os › S100 I/O › I/O Modules
-
Parts & Services › Control Systems › Compact Product Suite › I/Os › S100 I/O › I/O Modules
