Product Description
General Information
|
Field |
Details |
|---|---|
|
Manufacturer |
ABB |
|
Product ID |
57120001-CV |
|
ABB Type Designation |
DSTA 131 |
|
Catalog Description |
DSTA 131 Connection Unit for AI board |
|
Long Description |
DSTA 131 Connection Unit for Analog Board 16 Ch., 0.1% shunt, differential. See Spare Fuse 1 A / 3BSC770001R14 |
|
Medium Description |
DSTA 131 Connection Unit for Analog Input board |
|
Product Type |
I-O_Module |
Technical Information
|
Field |
Details |
|---|---|
|
Channel Count |
16 Analog Channels |
|
Measurement Type |
Differential |
|
Shunt Accuracy |
0.1% |
|
Fuse Requirement |
Spare Fuse 1 A (3BSC770001R14) |
Ordering Information
|
Field |
Details |
|---|---|
|
HS Code |
853890 (Electrical machinery and equipment parts) |
|
Customs Tariff Number |
85389091 |
Dimensions and Weight
|
Field |
Details |
|---|---|
|
Product Net Depth / Length |
324 mm |
|
Product Net Height |
54 mm |
|
Product Net Width |
153 mm |
|
Product Net Weight |
0.4 kg |
Environmental Compliance
|
Field |
Details |
|---|---|
|
RoHS Compliance |
Yes (EU Directive 2011/65/EU) |
|
WEEE Category |
5. Small Equipment (No External Dimension More Than 50 cm) |
|
Number of Batteries |
0 |
|
SCIP Number |
66fb8082-31e2-46ce-9f71-38c04eeacb1e (Sweden) |
Product Hierarchy
-
Products › Control System Products › I/O Products › S100 I/O › S100 I/O - Termination Units › DSTA 131 Connection Units
-
Products › Control Systems › Advant OCS with Master SW › Controllers › Advant Controller 450 (v2.3) › I/O Modules
-
Parts & Services › Control Systems › 800xA › I/Os › S100 I/O › I/O Modules
-
Parts & Services › Control Systems › Advant OCS with Master SW › Controllers › MasterPiece 200 and 200/1 › I/O Modules
-
Parts & Services › Control Systems › Advant OCS with MOD 300 SW › I/Os › S100 I/O › I/O Modules
-
Parts & Services › Control Systems › Compact Product Suite › I/Os › S100 I/O › I/O Modules
