Product Description
Product Overview
The ABB PM862K01 (Product ID: 3BSE076940R1) is a Processor Unit designed for the AC 800M control system. Featuring a 67 MHz processor and 32 MB of memory, it serves as a central unit for industrial automation, compatible with 800xA 6.0.2, Compact Control Builder 6.0.0-1, and later versions. The kit includes essential components for integration, though no software license is provided.
Technical Specifications
The PM862K01 Processor Unit has the following specifications:
| Item | Specification |
|---|---|
| Model | PM862K01 |
| Product ID | 3BSE076940R1 |
| Catalog Description | PM862K01 Processor Unit |
| Long Description | 67 MHz and 32 MB. Package including: - PM862, CPU - TP830, Baseplate - TB850, CEX-bus Terminator - TB807, ModuleBus Terminator - TB852, RCU-Link Terminator - Battery for memory backup (4943013-6) - No license included. Only compatible with 800xA 6.0.2, Compact Control Builder 6.0.0-1 and onwards. Please see Product Update for more information |
| Processor Speed | 67 MHz |
| Memory | 32 MB |
| Compatibility | 800xA 6.0.2, Compact Control Builder 6.0.0-1 and onwards |
| Package Contents | - PM862, CPU - TP830, Baseplate - TB850, CEX-bus Terminator - TB807, ModuleBus Terminator - TB852, RCU-Link Terminator - Battery for memory backup (4943013-6) |
| Product Net Depth / Length | 135 mm |
| Product Net Height | 186 mm |
| Product Net Width | 119 mm |
| Product Net Weight | 1.1 kg |
| Battery | Number: 1 Type: Portable Chemical Composition: Lithium Weight: 9 g |
Additional Details
The PM862K01 includes the following additional information:
| Category | Details |
|---|---|
| ABB Type Designation | PM862K01 |
| Medium Description | 67 MHz and 32 MB. Package including: - PM862, CPU - TP830, Baseplate - TB850, CEX-bus Terminator - TB807, ModuleBus Terminator - TB852, RCU-Link Terminator - Battery for memory backup (4943013-6) - No license included. Only compatible with 800xA 6.0.2, Compact Control Builder 6.0.0-1 and onwards. Please see Product Update for more information |
| Product Type | Central_Unit |
| HS Code | 853710 - Boards, panels, consoles, desks, cabinets and other bases, equipped with two or more apparatus of heading 85.35 or 85.36, for electric control or the distribution of electricity, including those incorporating instruments or apparatus of Chapter 90, and numerical control apparatus, other than switching apparatus of heading 85.17. - For a voltage not exceeding 1,000 V |
| Customs Tariff Number | 85371091 |
| Dangerous Goods UN Classification | Class 9: Miscellaneous Dangerous Substances and Articles, Including Environmentally Hazardous Substances |
| Dangerous Goods UN Number | UN3091-PI970 |
| RoHS Status | Following EU Directive 2011/65/EU |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| SCIP | fec5c94d-1555-43e1-8f80-a37697096e0d Sweden (SE) |
