Product Description
ABB GRBTU-01 3BSE013175R1 Remote Terminal Unit
Product Overview
- The ABB GRBTU-01, with part number 3BSE013175R1, is a Remote Terminal Unit (RTU) designed for use in ABB’s distributed control systems (DCS), particularly within the System 800xA or Advant OCS platforms. This module serves as a communication and control interface, enabling data acquisition from field devices and transmission to central control systems. It is commonly used in industries such as power distribution, water management, oil and gas, and industrial automation for remote monitoring and control of processes. The GRBTU-01 is known for its robust communication capabilities, reliability, and integration with ABB’s automation ecosystems.
Technical Specifications
- The GRBTU-01 3BSE013175R1 has the following specifications based on industry sources and ABB documentation:
| Specification | Details |
|---|---|
| Model/Part Number | 3BSE013175R1 |
| Designation | GRBTU-01 |
| Manufacturer | ABB |
| Description | Remote Terminal Unit for DCS Systems |
| Series | System 800xA, Advant OCS |
| Function | Acquires data from field devices and communicates with central control systems |
| Input Signals | Digital: Binary inputs (e.g., status signals) Analog: 4–20 mA, 0–10 V (configuration-dependent) |
| Output Signals | Digital: Relay or binary outputs Analog: 4–20 mA (configuration-dependent) |
| Communication Interfaces | Modbus RTU, PROFIBUS DP, IEC 60870-5-101/104, or ABB proprietary protocols |
| Data Rate | Up to 12 Mbps (protocol-dependent) |
| Connection Type | Serial (e.g., RS-232, RS-485), Ethernet, or fieldbus connections |
| Supported Devices | ABB S800 I/O modules, System 800xA controllers, field devices (sensors, actuators) |
| Diagnostics | Fault detection, communication status, signal errors |
| Compatibility | ABB System 800xA, Advant OCS, and related DCS platforms |
| Power Supply | 24 VDC (external or via system backplane) |
| Power Consumption | Approx. 5–10 W |
| Environmental Specifications | Operating Temperature: -25°C to +70°C (-13°F to +158°F) Storage Temperature: -40°C to +85°C (-40°F to +185°F) Relative Humidity: 5% to 95% non-condensing Vibration: IEC 60068-2-6 compliant Shock: IEC 60068-2-27 compliant |
| Enclosure | IP20 (installed in control cabinet or enclosure) |
| Dimensions | Approx. 150 mm (H) x 100 mm (W) x 120 mm (D) |
| Weight | Approx. 0.5–0.8 kg |
| Mounting | DIN-rail or panel mounting in system rack |
| Certifications | CE, UL, CSA, complies with IEC 61131 and IEC 61850 standards |
