Product Description
General Information
|
Field |
Details |
|---|---|
|
Product ID |
3BSE008546R1 |
|
ABB Type Designation |
AO820 |
|
Catalog Description |
AO820 Analog Output 4 ch |
|
Long Description |
±20mA, 0(4)…20mA, ±10V, 12bit + sign. Individually galvanic isolated channels. RL max 500 Ohms. Use Module Termination Unit TU810, TU812, TU814, TU830, TU833. |
|
Product Type |
I-O_Module |
|
Medium Description |
Same as Long Description |
Technical Specifications
|
Specification |
Details |
|---|---|
|
Channel Type |
AO (Analog Output) |
|
Number of Output Channels |
4 |
|
Signal Ranges |
±20 mA, 0(4)…20 mA, ±10 V |
|
Resolution |
12-bit + sign |
|
Galvanic Isolation |
Yes, individually isolated |
|
Load Resistance (RL max) |
500 Ohms |
Environmental
|
Specification |
Details |
|---|---|
|
RoHS Status |
Compliant with EU Directive 2011/65/EU |
|
WEEE Category |
Category 5 – Small Equipment (< 50 cm) |
|
Number of Batteries |
0 |
|
SCIP Number |
af202ecc-ba58-4efc-b180-019973c54b6f (Estonia) |
Dimensions & Weight
|
Dimension |
Value |
|---|---|
|
Net Depth / Length |
102 mm |
|
Net Height |
119 mm |
|
Net Width |
45 mm |
|
Net Weight |
0.3 kg |
Ordering & Compliance
|
Field |
Details |
|---|---|
|
HS Code |
853890 |
|
Customs Tariff Number |
85389099 |
Compatible Module Termination Units
-
TU810
-
TU812
-
TU814
-
TU830
-
TU833
