Product Description
General Information
|
Field |
Details |
|---|---|
|
Product ID |
3BSE008512R1 |
|
ABB Type Designation |
DI820 |
|
Catalog Description |
DI820 Digital Input 120V a.c. 8 ch |
|
Long Description |
Individually galvanic isolated channels. Use with TU811, TU813, TU831, TU839, TU851. |
|
Medium Description |
Same as Long Description |
|
Product Type |
I-O_Module |
Technical Specifications
|
Parameter |
Value |
|---|---|
|
Channel Type |
DI (Digital Input) |
|
Number of Input Channels |
8 |
|
Input Voltage |
120V AC |
|
Isolation |
Galvanic isolation on each individual channel |
|
Termination Unit Options |
TU811, TU813, TU831, TU839, TU851 |
Environmental Specifications
|
Parameter |
Value |
|---|---|
|
RoHS Status |
Compliant with EU Directive 2011/65/EU |
|
WEEE Category |
5. Small Equipment (No External Dimension > 50 cm) |
|
Number of Batteries |
0 |
|
SCIP Reference |
d3d14ac0-af33-40da-880a-13b138d27779 (Estonia) |
Ordering Information
|
Parameter |
Value |
|---|---|
|
HS Code |
853890 |
|
Customs Tariff Number |
85389099 |
Physical Dimensions
|
Dimension |
Value |
|---|---|
|
Net Depth / Length |
102 mm |
|
Net Height |
119 mm |
|
Net Width |
45 mm |
|
Net Weight |
0.3 kg |
Product Compatibility & System Integration
-
Product Family: S800 I/O
-
Catalog Path:
Products › Control System Products › I/O Products › S800 I/O › DI820 Digital Inputs
-
Compatible Control Systems:
-
ABB 800xA (Versions 4.0, 4.1, 5.0, 5.1, 6.0)
-
Compact Product Suite (Versions 4.1, 5.0, 5.1)
-
Advant OCS with Master SW and MOD 300 SW
-
Parts & Services Support For:
-
800xA: Versions 4.1, 5.0, 5.1
-
Compact Product Suite: Versions 4.1, 5.0, 5.1
