Product Description
General Information
|
Field |
Details |
|---|---|
|
Product ID |
3BHT300009R1 |
|
ABB Type Designation |
DO620 |
|
Catalog Description |
DO620 Digital Output 32ch, 60VDC |
|
Long Description |
32Ch, 60VDC Isolated, 4 groups |
|
Product Type |
I-O_Module |
|
Medium Description |
DO620 Digital Output 32Ch 60VDC Isolated, 4 groups |
Technical Specifications
|
Field |
Details |
|---|---|
|
System Family |
S600 I/O |
|
Channel Type |
DO (Digital Output) |
|
Number of Output Channels |
32 |
|
Output Voltage |
≤ 60 V DC |
|
Output Type |
Short-circuit proof transistors |
|
Isolation |
Opto-isolated in 4 groups |
|
Max Current per Channel |
0.5 A |
|
RoHS Compliance |
Exempt from 2011/65/EU (RoHS) under Article 2(4)(c), (e), (f), and (j) |
|
Reference |
3BSE088609 – EU Declaration of Conformity |
Dimensions & Weight
|
Field |
Value |
|---|---|
|
Product Net Depth / Length |
252 mm |
|
Product Net Height |
273 mm |
|
Product Net Width |
40 mm |
|
Product Net Weight |
1.2 kg |
Ordering Information
|
Field |
Value |
|---|---|
|
HS Code |
853890 |
|
Customs Tariff |
85389091 |
Environmental Compliance
|
Field |
Value |
|---|---|
|
RoHS Status |
Following EU Directive 2011/65/EU (Exempted, see above) |
|
WEEE Category |
5. Small Equipment (No External Dimension > 50 cm) |
|
Number of Batteries |
0 |
|
SCIP Code |
895376c2-d73c-413e-968c-bbe025e053cb (Sweden) |
Product Family & Compatibility
|
Field |
Details |
|---|---|
|
Product Line |
S600 I/O |
|
Applicable Systems |
Advant OCS with Master SW › Advant Controller 160 Version 2.2 |
|
Application |
Digital output control in process automation and safety-critical systems |
