Product Description
General Information
|
Field |
Description |
|---|---|
|
Product ID |
3BDH000377R0001 |
|
ABB Type Designation |
AX 722F Rev.A |
|
Catalog Description |
AX 722F Analog Input/Output Module |
|
Long Description |
16-channel analog I/O module: 8 configurable AI (Voltage, Current, RTD) and 8 AO (4 configurable U/I, 4 U only). Electrically isolated from internal circuitry (no isolation between channels). Suitable for PROFIBUS remote I/O and AC700F/AC900F direct I/O. |
|
Product Type |
I-O_Module |
|
Medium Description |
For PROFIBUS Slave and direct I/O. Use with TU 715F / TU 716F |
Technical Specifications
|
Parameter |
Value |
|---|---|
|
Channel Type |
AX |
|
Total Channels |
16 |
|
Input Channels (AI) |
8 (±10 V, 0/4–20 mA, RTD, 24 VDC) |
|
Output Channels (AO) |
8 |
|
AO Configuration |
4 AO configurable (±10 V, 0/4–20 mA), 4 AO fixed (±10 V) |
|
Input/Output Isolation |
Inputs and outputs isolated from internal electronics, not from each other |
|
Signal Resolution |
12-bit + sign |
|
Wire Type |
2-wire |
|
Compatible Terminal Units |
TU 715F, TU 716F |
Environmental Compliance
|
Parameter |
Value |
|---|---|
|
RoHS Compliance |
Compliant with EU Directive 2011/65/EU and Amendment 2015/863 (July 22, 2019) |
|
WEEE Category |
Category 5 – Small Equipment (No External Dimension > 50 cm) |
|
Number of Batteries |
0 |
Dimensions & Weight
|
Parameter |
Value |
|---|---|
|
Net Dimensions (D x H x W) |
54 mm x 76 mm x 67.5 mm |
|
Net Weight |
0.13 kg |
Ordering Information
|
Parameter |
Value |
|---|---|
|
HS Code |
853890 |
|
Customs Tariff Number |
85389099 |
Applications
-
PROFIBUS-based Remote I/O
-
Direct I/O with ABB AC700F and AC900F controllers
-
Flexible analog signal processing in automation systems
