Product Description
General Information
|
Attribute |
Details |
|---|---|
|
Product ID |
3BDH000376R0005 |
|
ABB Type Designation |
AI 723F Rev. B |
|
Catalog Description |
AI 723F Analog Input Module |
|
Long Description |
16 input channels in two groups, configurable for voltage, current, temperature, or digital inputs. Electrically isolated inputs, usable with PROFIBUS remote I/O and AC 700F / AC 900F direct I/O. |
|
ABB Product Family |
Freelance Control Hardware |
|
Channel Type |
Analog Input (AI) |
|
Product Name |
I-O Module |
|
Product Type |
I-O_Module |
|
Short Description |
AI 723F Rev. B Analog Input Module |
|
Replaced Product ID |
3BDH000376R0001 |
Ordering & Classification
|
Attribute |
Details |
|---|---|
|
EAN |
4013614503214 |
|
Country or Territory of Origin |
Germany, United States |
|
Customs Tariff Number (CN8) |
85389099 |
|
HS Code |
853890 |
|
Invoice Description |
AI 723F Analog Input Module |
|
Made To Order |
No |
|
Minimum Order Quantity |
1 piece |
|
Order Multiple |
1 piece |
|
Selling Unit of Measure |
piece |
|
Part Type |
New |
|
RoHS Status |
Compliant with EU Directive 2011/65/EU and Amendment 2015/863 (July 22, 2019) |
|
SCIP Number |
94fea1e9-d2ba-4c06-8a2f-3deefa24c1af (Germany) |
|
WEEE B2C / B2B |
Business To Business |
|
WEEE Category |
5. Small Equipment (No External Dimension More Than 50 cm) |
Technical Specifications
|
Attribute |
Details |
|---|---|
|
Number of Input Channels |
16 |
|
Input Types Supported |
Voltage (0…10 V or -10…+10 V), Current (0…20 mA or 4…20 mA), Temperature sensors (Pt100, Pt1000, Ni1000), Digital Inputs |
|
Input Configuration |
2-wire or 3-wire |
|
Resolution |
12 Bit + sign |
|
Isolation |
Inputs electrically isolated from module electronics, no potential separation between channels |
|
Compatible with |
PROFIBUS remote I/O, AC 700F / AC 900F direct I/O, TU 715 F / TU 716F |
Dimensions & Weight
|
Attribute |
Details |
|---|---|
|
Product Net Weight |
0.15 kg |
|
Product Net Depth / Length |
76 mm |
|
Product Net Height |
54 mm |
|
Product Net Width |
68 mm |
|
Gross Weight |
0.15 kg |
Stock Locations
-
Menden, Germany
-
Västerås, Sweden
-
Wickliffe, Ohio, United States
-
Ratingen, Germany
-
Singapore, Singapore
