1X00416H01 Emerson Ovation WH5-2FF Dual 24VDC Power Supply Module

⚡ Redundant Power Architecture for Mission-Critical DCS Operations

The 1X00416H01 WH5-2FF delivers enterprise-grade power distribution for Emerson Ovation distributed control systems, featuring dual independent 24 VDC outputs engineered for maximum uptime in power generation, petrochemical, and industrial automation environments. This hot-swappable power module ensures continuous operation even during maintenance or component failure, making it the backbone of fault-tolerant control architectures.

🔋 Power System Specifications

• Model Designation: 1X00416H01 WH5-2FF
• Output Voltage: Dual 24 VDC regulated outputs
• Total Power Capacity: 120W combined (60W per output)
• Input Voltage Range: 100-240 VAC, 50/60 Hz auto-sensing
• Efficiency Rating: >85% at full load (Energy Star compliant)
• Holdup Time: 20ms minimum at full load
• Ripple & Noise: <50mV peak-to-peak
• Overload Protection: Electronic current limiting with auto-recovery
• Thermal Management: Convection cooling, no fan required
• MTBF: >200,000 hours at 40°C ambient
• Certifications: UL508, CE, RoHS, REACH compliant

🏗️ Critical Infrastructure Applications

Power Plant Operations: Supply stable DC power to Ovation controllers, I/O racks, and HMI workstations in coal-fired, combined-cycle, and nuclear generating stations where grid stability depends on uninterrupted control system operation during load transients and switchover events.

Offshore Oil & Gas Platforms: Withstand harsh marine environments with conformal-coated circuitry resistant to salt spray, humidity, and vibration—ensuring reliable power delivery to safety-critical shutdown systems and process monitoring equipment in ATEX Zone 2 classified areas.

Continuous Process Manufacturing: Power 24/7 production lines in pulp & paper mills, steel rolling operations, and chemical batch reactors where even millisecond power interruptions can trigger emergency stops costing $50,000-$500,000 per incident in lost production and material waste.

🚀 Advanced Design Features

N+1 Redundancy Support: Deploy multiple WH5-2FF modules in parallel configurations with automatic load sharing and seamless failover—if one supply fails, remaining units instantly absorb the load without voltage droop or system reset.

Diagnostic Intelligence: Built-in status LEDs and relay contacts provide real-time health monitoring with early warning indicators for AC input loss, DC output fault, and thermal overload conditions—integrate these signals into your SCADA system for centralized power infrastructure visibility.

Wide Operating Temperature Range: Proven performance from -20°C to +70°C enables installation in non-climate-controlled equipment rooms, outdoor enclosures, and industrial environments without derating or auxiliary cooling systems.

🔧 Installation & Maintenance Advantages

DIN rail mounting with tool-free clip installation accelerates commissioning—typical rack integration takes under 5 minutes per module. Removable terminal blocks with captive screws prevent wire loss during service. The hot-swap capability allows technicians to replace failed units during operation without process shutdown, supporting zero-downtime maintenance strategies.

📋 Complete Package Contents

• 1X00416H01 WH5-2FF power supply module
• DIN rail mounting clips (pre-installed)
• Removable screw terminal blocks (input/output)
• Status indicator label and wiring diagram
• Factory test report with serial number traceability

✅ Quality & Lifecycle Support

Manufactured in ISO 9001:2015 certified facilities with 100% automated optical inspection and power-on testing. Each unit ships with calibration data traceable to international standards. Emerson guarantees spare parts availability for 15+ years and offers global field service support with 4-hour emergency response in major industrial regions.
