Product Description
General Information
|
Field |
Details |
|---|---|
|
Extended Product Type |
DI562 |
|
Product ID |
1TNE968902R2102 |
|
ABB Type Designation |
DI562 |
|
EAN |
6943747170220 |
|
Catalog Description |
Digital input module. 16 DI sink/source: 24VDC |
|
Long Description |
S500-eCo Digital input module. 16 DI sink/source: 24VDC. 1-wire |
|
Product Name |
Distributed Automation I/Os |
|
Product Main Type |
DI562 |
Technical Specifications
|
Parameter |
Value |
|---|---|
|
Function |
16 DI sink/source |
|
Input Voltage Type |
AC/DC |
|
Input Voltage Range |
0 … 30 V |
|
Input Current |
5 mA |
|
Delay Time (τ) |
8 … 8 ms |
|
Number of Digital Inputs |
16 |
|
Number of Configurable I/Os |
0 |
|
Connection Type |
Pluggable |
|
Degree of Protection |
IP20 |
|
Ambient Temperature (Operation) |
0 … +60 °C |
|
Ambient Temperature (Storage) |
-40 … +70 °C |
Ordering Information
|
Field |
Details |
|---|---|
|
CN8 (HS Code) |
85371091 |
|
Invoice Description |
Digital input module. 16 DI sink/source: 24VDC (DI562) |
|
Made To Order |
No |
|
Minimum Order Quantity |
1 piece |
|
Order Multiple |
1 piece |
|
Selling Unit of Measure |
Piece |
Dimensions & Weight
|
Parameter |
Value |
|---|---|
|
Net Weight |
0.116 kg |
|
Net Depth / Length |
135 mm |
|
Net Height |
74 mm |
|
Net Width |
34 mm |
|
Gross Weight |
0.215 kg |
|
Package Dimensions (L × W × H) |
93 × 170 × 63 mm |
|
Package Units (Level 1) |
1 carton |
Environmental Compliance
|
Parameter |
Value |
|---|---|
|
RoHS Status |
Compliant with EU Directive 2011/65/EU + Amendment 2015/863 |
|
RoHS Date |
2009 |
|
REACH Date |
2024-12-06 |
|
REACH Declaration |
Yes (contains substances > 0.1 mass %) |
|
SCIP Reference |
2a5298d5-fdc0-42f2-82a6-f96a09eb394f (China) |
|
WEEE Category |
5. Small Equipment (No External Dimension > 50 cm) |
|
WEEE B2C/B2B |
Business To Business |
Classification Standards
|
Standard |
Code |
|---|---|
|
eClass |
27-24-22-04 |
|
ETIM 8/9/10 |
EC001419 - PLC digital I/O-module |
|
UNSPSC |
32151705 |
