1SDA054365R1 | ABB T5L 400 PR221DS-LS Molded Case Circuit

1SDA054365R1 | ABB T5L 400 PR221DS-LS Molded Case Circuit

  • Manufacturer: ABB

  • Product No.: 1SDA054365R1

  • Condition:1000 in stock

  • Product Type: Molded Case Circuit

  • Product Origin: Sweden

  • Payment: T/T, Western Union

  • Weight: 5100g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Overview

Feature Specification
Product ID 1SDA054365R1
ABB Global ID ABB1SDA054365R1
EAN 8015644554637
Catalog Description T5L 400 PR221DS-LS/I In=400 3p F F
Long Description C.BREAKER TMAX T5L 400 FIXED THREE-POLE WITH FRONT TERMINALS AND SOLID-STATE RELEASE IN AC PR221DS-LS-I R 400
Life Cycle Phase Active
Product Type Automatic Circuit Breaker
Suitable For T5
Minimum Order Quantity 1 piece
Customs Tariff Number 85362090
ECCN N
Product Main Type SACE Tmax T
Gross Weight 5.1 kg
Package Level 1 Gross Weight 5.1 kg
Package Level 1 Units 1 piece
Producing Unit ITSCE

Environmental Information

  • RoHS Status: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
  • REACH Declaration: Available
  • Toxic Substances Control Act (TSCA): Declaration available
  • Packaging Disposal Information: Available
  • WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)

Technical Information

  • Rated Current (In): 400 A
  • Rated Impulse Withstand Voltage (Uimp): 8 kV
  • Rated Insulation Voltage (Ui): 1000 V
  • Rated Operational Voltage: 690 V AC
  • Rated Service Short-Circuit Breaking Capacity (Ics):
    • (220 V AC) 200 kA
    • (230 V AC) 200 kA
    • (380 V AC) 120 kA
    • (400 V AC) 120 kA
    • (415 V AC) 120 kA
    • (440 V AC) 100 kA
    • (500 V AC) 85 kA
    • (690 V AC) 70 kA
  • Rated Ultimate Short-Circuit Breaking Capacity (Icu): Same values as Ics
  • Rated Uninterrupted Current (Iu): 400 A
  • Mechanical Durability: 20000 cycles, 120 cycles per hour
  • Electrical Durability: 7000 cycles, 60 cycles per hour
  • Release Type: EL, PR221DS-LS/I
  • Terminal Connection Type: Fixed Circuit-Breakers Front

Certificates and Declarations

  • Data Sheet, Technical Information: 1SDC210004D0203
  • Declaration of Conformity - CE: EC Declaration of Conformity Tmax T5
  • GL Certificate: 1SDL000163R0062
  • Installation Instructions: Tmax T5 Installation Instructions

Standards and Classifications

  • Standards: IEC
  • ETIM 9: EC000228 - Power circuit-breaker for transformer/generator/installation protection
  • UNSPSC: 39121100
  • eClass: V11.1 : 27370409
