Product Description
General Information
|
Parameter |
Value |
|---|---|
|
Manufacturer |
ABB |
|
Extended Product Type |
CP6610 |
|
Product ID |
1SAP561010R0001 |
|
ABB Type Designation |
CP6610 |
|
EAN |
4013614529634 |
|
Catalog Description |
Control panel with 10.1” TFT multi-touch screen, 16M colors, 1280 x 800 pixel, Chromium Browser |
|
Long Description |
CP6610: CP600-Pro Control panel with 10.1” TFT multi-touch screen, 16M colors, 1280 x 800 pixel, Chromium Browser, PB610 applications |
Technical Specifications
|
Parameter |
Value |
|---|---|
|
Function |
10.1” TFT multi-touch screen, 16M colors, 1280 x 800 pixel, Chromium Browser |
|
Screen Size |
10.1 inches |
|
Screen Color |
16M (16,000,000) colors |
|
Screen Resolution |
1280 x 800 pixels |
|
Display Type |
TFT, capacitive multitouch |
|
Number of Hardware Interfaces |
|
|
- Industrial Ethernet |
3 |
|
- Other |
1 |
|
- Parallel |
0 |
|
- RS-232 |
0 |
|
- RS-422 |
0 |
|
- RS-485 |
0 |
|
- Serial TTY |
0 |
|
- USB |
2 |
|
- Wireless |
0 |
|
- PROFINET |
0 |
|
Memory Size |
240000 kB |
|
Security |
50 |
|
Input Voltage Type |
DC |
|
Supply Voltage |
18 – 32 V DC |
|
Degree of Protection (Front) |
IP66 |
|
Built-In Depth (t2) |
52 mm |
|
Ambient Air Temperature (Operation) |
-20 to +60 °C |
Dimensions & Weight
|
Parameter |
Value |
|---|---|
|
Product Net Weight |
1.7 kg |
|
Product Net Depth / Length |
64 mm |
|
Product Net Height |
197 mm |
|
Product Net Width |
282 mm |
|
Gross Weight |
2.5 kg |
|
Package Level 1 Depth / Length |
370 mm |
|
Package Level 1 Height |
120 mm |
|
Package Level 1 Width |
270 mm |
|
Package Level 1 Units |
1 carton |
Ordering Information
|
Parameter |
Value |
|---|---|
|
CN8 |
85371091 |
|
Invoice Description |
Control panel, 10.1” TFT multi-touch screen, 16M colors, 1280 x 800 pixel, Chromium Browser (CP6610) |
|
Made To Order |
No |
|
Minimum Order Quantity |
1 piece |
|
Order Multiple |
1 piece |
|
Selling Unit of Measure |
Piece |
External Classifications and Standards
|
Parameter |
Value |
|---|---|
|
eClass |
27-33-02-01 |
|
ETIM 8 |
EC001412 - Graphic panel |
|
ETIM 9 |
EC001412 - Graphic panel |
|
ETIM 10 |
EC001412 - Graphic panel |
|
UNSPSC |
32151703 |
Environmental Information
|
Parameter |
Value |
|---|---|
|
SCIP |
1ee17d0f-5264-43f0-a1ed-f5092f74b01c (Germany) |
|
WEEE B2C / B2B |
Business To Business |
|
WEEE Category |
5. Small Equipment (No External Dimension More Than 50 cm) |
