Product Description
LEM LF 1005-S/SP16 Current Transducer (Industrial-Grade Open-Loop Spare)
The LEM LF 1005-S/SP16 is a high-precision, open-loop current transducer engineered for demanding industrial environments. Designed to measure AC, DC, and pulsed currents with exceptional accuracy, this unit is a critical component in variable frequency drives (VFDs), servo controllers, UPS systems, and industrial inverters. When your production line depends on precise current feedback, the LF 1005-S/SP16 delivers the measurement integrity your system demands — without compromise.
As an original LEM spare, this transducer is manufactured to OEM specifications, ensuring seamless drop-in replacement for aging or failed units. Whether you're managing a planned maintenance schedule or responding to an unplanned shutdown, having this component in your spares inventory is a strategic decision that protects uptime and reduces mean time to repair (MTTR).
Critical Technical Specs
| Parameter | Specification |
|---|---|
| Model | LEM LF 1005-S/SP16 |
| Measurement Principle | Open-Loop (Hall Effect) |
| Nominal Current (RMS) | 1000 A |
| Measuring Range | 0 – 1500 A peak |
| Supply Voltage | ±15 V DC (±5%) |
| Output Signal | Voltage output (±4 V at nominal) |
| Accuracy | ±1% at nominal current |
| Frequency Bandwidth (−3dB) | DC – 10 kHz |
| Operating Temperature | −25°C to +70°C |
| Isolation Voltage | 3 kV RMS / 50 Hz / 1 min |
| Conductor Aperture | SP16 (16 mm × 16 mm) |
| Standards | IEC 61010-1, CE Marked |
| Warranty | 12 Months from date of shipment |
