Product Description
Mahsulot tafsilotlari
-
Ishlab chiqaruvchi: Bently Nevada
-
Seriya: 3500/15
-
Model/Qism raqami: 133300-01
-
Model Turi: Legacy Past Kuchlanishli DC Quvvat Kirish Moduli
Tavsif
3500/15 Legacy Past Kuchlanishli DC Quvvat Kirish Moduli 3500/15 AC va DC Quvvat Ta'minotlari bilan ishlash uchun mo'ljallangan va 3500 shkafi ning chap tomonidagi belgilangan slotlarga o'rnatiladi. Modul tizimga bir yoki ikki quvvat ta'minotini har qanday AC va DC kombinatsiyasida qabul qilish imkonini beradi. Bitta quvvat ta'minoti to'liq shkafni quvvatlantirishi mumkin, bu tizimni juda moslashuvchan va kengaytiriladigan qiladi.
Texnik xususiyatlar
| Atribut |
Tafsilotlar |
| Kirishlar |
Universal AC, past kuchlanishli DC |
| Kirish kuchlanishi (universal AC) |
110 dan 220 Vac (nominal), 85 dan 264 Vac (xavfsiz hududlar), 85 dan 250 Vac (xavfli hududlar), 120 dan 373 Vac pk |
| Kirish chastotasi |
47 dan 63 Hz gacha |
| Kirish kuchlanishi (past kuchlanishli DC) |
20 dan 30 Vdc gacha |
| Ishlash harorati |
-30°C dan +65°C gacha (-22°F dan +150°F gacha) |
| Saqlash harorati |
-40°C dan +85°C gacha (-40°F dan +185°F gacha) |
| Namlik |
95%, kondensatsiyasiz |
Atrof-muhit chegaralari
-
Ishlash harorati: -30°C dan +65°C gacha (-22°F dan +150°F gacha)
-
Saqlash Harorati: -40°C dan +85°C gacha (-40°F dan +185°F gacha)
-
Namlik: 95%, kondensatsiyasiz
Jismoniy O'lchamlar
| Atribut |
Tafsilotlar |
| O'lchamlar |
120.7 mm x 25.4 mm x 114.3 mm (4.75 in x 1.0 in x 4.5 in) |
| Og'irlik |
0.34 kg (0.75 lb) |
Buyurtma Ma'lumotlari
3500/15 Quvvat Kirish Moduli uchun qism raqami formati quyidagicha:
| A: Quvvat Ta'minoti Turi (Yuqori Slot) |
Variantlar |
| 03 |
An'anaviy Yuqori Kuchlanishli DC (88 dan 140 Vdc gacha) |
| 04 |
An'anaviy Past Kuchlanishli DC (20 dan 30 Vdc gacha) |
| 05 |
Universal AC Kuchlanishi (85 dan 264 Vac rms gacha) |
| 06 |
Yuqori Kuchlanishli DC Ta'minoti |
| 07 |
Past Kuchlanishli DC Ta'minoti |
| B: Quvvat Ta'minoti Turi (Pastki Slot) |
Variantlar |
| 00 |
Ta'minotsiz (ta'minot talab qilinmaganda ishlatiladi) |
| 03 |
An'anaviy Yuqori Kuchlanishli DC (88 dan 140 Vdc gacha) |
| 04 |
An'anaviy Past Kuchlanishli DC (20 dan 30 Vdc gacha) |
| 05 |
Universal AC Kuchlanishi (85 dan 264 Vac rms gacha) |
| 06 |
Yuqori Kuchlanishli DC Ta'minoti |
| 07 |
Past Kuchlanishli DC Ta'minoti |
| C: Agentlik Tasdiqlashi |
Variantlar |
| 00 |
Yo'q |
| 01 |
CSA / NRTL / C (1-sinf, 2-bo'lim) |
