Product Description
Mahsulot tafsilotlari
| Ishlab chiqaruvchi | Bently Nevada |
|---|---|
| Seriya | 3500/15 |
| Model/Qism raqami | 3500/15 133292-01 |
| Model turi | Quvvat Ta'minoti Moduli |
Tavsif
3500/15 AC va DC quvvat manbalari yarim balandlikdagi modullar bo'lib, 3500 shkafining chap tomonidagi belgilangan joylarga mos keladi. Ushbu quvvat manbalari moslashuvchan konfiguratsiyani ta'minlaydi, shkafda bir yoki ikki quvvat manbai turli AC va DC kombinatsiyalarida joylashishi mumkin. Har bir quvvat manbai to'liq shkafni quvvatlantira oladi.
Atrof-muhit chegaralari
| Shart | Harorat oralig'i |
|---|---|
| Ishlash harorati | -30 °C dan +65 °C gacha (-22 °F dan +150 °F gacha) |
| Saqlash harorati | -40 °C dan +85 °C gacha (-40 °F dan +185 °F gacha) |
| Namlik | 95%, kondensatsiyasiz |
Jismoniy Texnik Tavsiflar
| Komponent | O'lchamlar (B x K x Ch) | Og'irlik |
|---|---|---|
| Quvvat Ta'minoti Moduli | 120.7 mm x 50.8 mm x 251.5 mm (4.75 dyuym x 2.0 dyuym x 9.9 dyuym) | 1.39 kg (3.06 funt) |
Texnik xususiyatlar
| Kirish kuchlanishi variantlari | Tafsilotlar |
|---|---|
| Universal Kuchlanish AC | Kirish: 110 dan 220 Vac nominal (xavfsiz hududlar) 85 dan 264 Vac rms (xavfsiz) 85 dan 250 Vac rms (xavfli) 120 dan 373 Vac cho'qqisi (xavfli hududlar uchun) Kirish chastotasi: 47 dan 63 Gts gacha |
| Past kuchlanishli DC | Kirish: 20 dan 30 Vdc gacha |
Oqim ma'lumotlari
-
To'liq shkaf oqim tortishi:
- Universal AC: Maksimal 2.8 A rms
- Yuoqri kuchlanishli DC: Maksimal 2.5 A
- Past kuchlanishli DC: Maksimal 11.0 A
-
Himoya:
- Past kuchlanish: Ta'minot yoki Quvvat kirish moduli (PIM)ga zarar yetmaydi.
- Ortacha kuchlanish: PIMdagi sigortani ochadi.
Buyurtma Ma'lumotlari
| Model formati | 3500/15-AA-BB-CC |
|---|---|
| A: Quvvat Ta'minoti Turi (Yuqori Slot) |
03: Meros qolgan yuqori kuchlanishli DC (88 dan 140 Vdc gacha) 04: Meros qolgan past kuchlanishli DC (20 dan 30 Vdc gacha) 05: Universal AC kuchlanishi (85 dan 264 Vac rms gacha) 06: Yuqori kuchlanishli DC ta'minoti 07: Past kuchlanishli DC ta'minoti |
| B: Quvvat Ta'minoti Turi (Pastki Slot) |
00: Ta'minotsiz (ta'minot talab qilinmaganida ishlatiladi) 03: Meros qolgan yuqori kuchlanishli DC (88 dan 140 Vdc gacha) 04: Meros qolgan past kuchlanishli DC (20 dan 30 Vdc gacha) 05: Universal AC kuchlanishi (85 dan 264 Vac rms gacha) 06: Yuqori kuchlanishli DC ta'minoti 07: Past kuchlanishli DC ta'minoti |
| C: Agentlik Tasdiqlashi |
00: Yo'q 01: CSA / NRTL / C (1-sinf, 2-bo'lim) |
