Product Description
Mahsulot tafsilotlari
| Ishlab chiqaruvchi | Bently Nevada |
|---|---|
| Seriya | 3500/15 |
| Model/Qism raqami | 3500/15-05-05-00, 106M1079-01, 106M1081-01 |
| Model turi | AC va DC Quvvat Ta'minotlari |
Zaxira qismlar
| Qism raqami | Tavsif |
|---|---|
| 106M1079-01 | Universal AC Quvvat Moduli |
| 106M1081-01 | Universal AC Quvvat Kirish Moduli |
Tavsif
The 3500/15 AC va DC Quvvat Manbalari yarim balandlikdagi modullar bo'lib, shkafning chap tomonidagi belgilangan joylarga o'rnatilishi kerak. 3500 shkafi har qanday AC va DC kombinatsiyasida bitta yoki ikkita quvvat manbasini o'z ichiga olishi mumkin. Har bir quvvat manbai to'liq shkafni quvvatlantira oladi.
Texnik xususiyatlar
Kirishlar
| Kuchlanish Variantlari | Tavsif |
|---|---|
| Universal Kuchlanish AC | Kirish kuchlanishi: 110 dan 220 Vac nominal |
| Xavfsiz hududlar: 85 dan 264 Vac rms gacha | |
| Xavfli hududlar: 85 dan 250 Vac rms gacha | |
| Cho'qqi kuchlanishi: 120 dan 373 Vac pk gacha | |
| Kirish chastotasi: 47 dan 63 Gts gacha | |
| Eslatma: Meros qolgan Yuqori Kuchlanish AC yoki Past Kuchlanish AC birliklari bilan mos emas. | |
| Yuqori kuchlanishli DC | Kirish kuchlanishi: 88 dan 140 Vdc gacha |
| Past kuchlanishli DC | Kirish kuchlanishi: 20 dan 30 Vdc gacha |
Jismoniy
| Modul turi | O'lchamlar (B x K x Ch) | Og'irlik |
|---|---|---|
| Quvvat Ta'minoti Moduli | 120.7 mm x 50.8 mm x 251.5 mm | 1.39 kg (3.06 funt) |
| Quvvat kirish moduli | 120.7 mm x 25.4 mm x 114.3 mm | 0.34 kg (0.75 lb) |
Atrof-muhit chegaralari
| Parametr | Oraliq |
|---|---|
| Ishlash harorati | -30°C dan +65°C gacha (-22°F dan +150°F gacha) |
| Saqlash harorati | -40°C dan +85°C gacha (-40°F dan +185°F gacha) |
| Namlik | 95%, kondensatsiyasiz |
Buyurtma Ma'lumotlari
| Model/Qism raqami | Tavsif |
|---|---|
| 3500/15 Quvvat Ta'minoti Moduli | 3500/15 -AA-BB-CC |
| A: Quvvat manbai turi (yuqori slot) | 03: Meros Yuqori Kuchlanishli DC (88 dan 140 Vdc gacha) |
| 04: Meros Past Kuchlanishli DC (20 dan 30 Vdc gacha) | |
| 05: Universal AC Kuchlanishi (85 dan 264 Vac rms gacha) | |
| 06: Yuqori Kuchlanishli DC Ta'minoti | |
| 07: Past Kuchlanishli DC Ta'minoti | |
| B: Quvvat manbai turi (pastki slot) | 00: Ta'minot yo'q (ta'minot talab qilinmasa) |
| 03: Meros Yuqori Kuchlanishli DC (88 dan 140 Vdc gacha) | |
| 04: Meros Past Kuchlanishli DC (20 dan 30 Vdc gacha) | |
| 05: Universal AC Kuchlanishi (85 dan 264 Vac rms gacha) | |
| 06: Yuqori Kuchlanishli DC Ta'minoti | |
| 07: Past Kuchlanishli DC Ta'minoti | |
| C: Agentlik tasdiqlashi | 00: Yo'q |
| 01: CSA / NRTL / C (1-sinf, 2-bo'lim) |
