Bently Nevada 3500/15-05-00-00 Quvvat ta'minoti moduli

Mahsulot tafsilotlari

• Ishlab chiqaruvchi: Bently Nevada
• Seriya: 3500/15
• Model/Qism raqami: 3500/15-05-00-00
• Model turi: Quvvat ta'minoti moduli

Texnik xususiyatlar

Kirishlar

• Voltaj Variantlari:

  • Universal Kuchlanish AC:

    • Universal AC Quvvat manbai va universal AC Quvvat Kirish Moduli (PIM) dan foydalanadi.
    • Kirish kuchlanishi:
      • Nominal: 110 dan 220 Vac gacha
      • Xavfsiz hududlar: 85 dan 264 Vac rms
      • Xavfli hududlar: 85 dan 250 Vac rms / 120 dan 373 Vac cho'qqi
    • Eslatma: Universal AC Quvvat Manbai va PIM eski Yuqori Kuchlanishli yoki Past Kuchlanishli AC birliklari bilan mos emas.
    • Kirish Chastotasi: 47 dan 63 Hz gacha

  • Yuqori kuchlanishli DC:

    • Yuqori Kuchlanishli DC Quvvat Manbai va Yuqori Kuchlanishli DC Quvvat Kirish Moduli (PIM) dan foydalanadi.
    • Kirish Kuchlanishi: 88 dan 140 Vdc gacha

  • Past kuchlanishli DC:

    • Past Kuchlanishli DC Quvvat Manbai va Past Kuchlanishli DC Quvvat Kirish Moduli (PIM) dan foydalanadi.
    • Kirish Kuchlanishi: 20 dan 30 Vdc gacha

Jismoniy Texnik Tavsiflar

• Quvvat Manbai Modulining O'lchamlari:
  • 120.7 mm x 50.8 mm x 251.5 mm (Balandlik x Kenglik x Chuqurlik)
  • 4.75 dyuym x 2.0 dyuym x 9.9 dyuym
• Ogʻirligi:
  • 1.39 kg (3.06 funt)

Rack uchun joy talablari

• Ikkita yarim balandlikdagi slot shkafning chap tomonida joylashgan.
• Har bir slot bitta quvvat manbai modulini sig'dira oladi.
• Ikkala slot ham zaxira quvvat manbalari uchun bir vaqtda ishlatilishi mumkin.

Buyurtma Ma'lumotlari

Qism raqami formati 3500/15-AA-BB-CC.

• A: Quvvat Ta'minoti Turi (Yuqori Slot):

  • 03: Meros Yuqori Kuchlanishli DC (88 dan 140 Vdc gacha)
  • 04: Meros Past Kuchlanishli DC (20 dan 30 Vdc gacha)
  • 05: Universal AC Kuchlanishi (85 dan 264 Vac rms gacha)
  • 06: Yuqori Kuchlanishli DC Ta'minoti
  • 07: Past Kuchlanishli DC Ta'minoti

• B: Quvvat Ta'minoti Turi (Pastki Slot):

  • 00: Quvvat manbai yo'q (agar quvvat manbai talab qilinmasa)
  • 03: Meros Yuqori Kuchlanishli DC (88 dan 140 Vdc gacha)
  • 04: Meros Past Kuchlanishli DC (20 dan 30 Vdc gacha)
  • 05: Universal AC Kuchlanishi (85 dan 264 Vac rms gacha)
  • 06: Yuqori Kuchlanishli DC Ta'minoti
  • 07: Past Kuchlanishli DC Ta'minoti

• C: Agentlik Tasdiqlashi:

  • 00: Yo'q
  • 01: CSA / NRTL / C (1-sinf, 2-bo'lim)
  • 02: ATEX / IECEx / CSA (1-sinf, 2-zona)
