Honeywell FC-FANWR-24R 24 V DC Fan Unit with Readback

Honeywell FC-FANWR-24R 24 V DC Fan Unit with Readback

  • Manufacturer: Honeywell

  • Product No.: FC-FANWR-24R

  • Condition:1000 in stock

  • Product Type: 24 V DC Fan Unit with Readback

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Overview

Parameter Details
Part Number FC-FANWR-24R
Product Name 24 V DC Fan Unit with Readback
Application Ventilation unit for ControlEdge HC900 and Safety Manager systems
Compatibility Compatible with Honeywell ControlEdge HC900 and Safety Manager racks
Function Provides cooling for control system racks with status monitoring

Functional Specifications

Parameter Details
Fan Configuration Two fans on a mounting plate with PCB (07209)
Power Supply 24 V DC, external via 4-pole connector
Power Consumption Not specified; typical for dual fan units
Status Monitoring Green LED per fan indicates speed above minimum; readback contact closes if both fans operational
Airflow Direction Directed through rack for optimal cooling (bottom to top)
Safety Features Finger guards on both sides of fans
Ambient Temperature Range -40 to 70°C
Mounting Integrated into control system rack
Standards Compliance CE, UL, designed for hazardous locations (HAZLOC)



View full details

Product Description

Product Overview

Parameter Details
Part Number FC-FANWR-24R
Product Name 24 V DC Fan Unit with Readback
Application Ventilation unit for ControlEdge HC900 and Safety Manager systems
Compatibility Compatible with Honeywell ControlEdge HC900 and Safety Manager racks
Function Provides cooling for control system racks with status monitoring

Functional Specifications

Parameter Details
Fan Configuration Two fans on a mounting plate with PCB (07209)
Power Supply 24 V DC, external via 4-pole connector
Power Consumption Not specified; typical for dual fan units
Status Monitoring Green LED per fan indicates speed above minimum; readback contact closes if both fans operational
Airflow Direction Directed through rack for optimal cooling (bottom to top)
Safety Features Finger guards on both sides of fans
Ambient Temperature Range -40 to 70°C
Mounting Integrated into control system rack
Standards Compliance CE, UL, designed for hazardous locations (HAZLOC)
