ALLEN BRADLEY 1756-PA72/K ControlLogix Standart AC Quvvat Manbai
ALLEN BRADLEY 1756-PA72/K ControlLogix Standart AC Quvvat Manbai
Manufacturer: ALLEN BRADLEY
Product No.: 1756-PA72/K
Condition:Omborda 1000 ta mavjud
Product Type: ControlLogix Standart AC Quvvat Manbai
Product Origin: USA
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Qo'llab-quvvatlash
- 30-Kunlik Qaytarishlar
- Tez yetkazib berish
Mahsulotga umumiy nazar
| Parametr | Ma'lumotlar |
|---|---|
| Qism raqami | 1756-PA72/K |
| Mahsulot nomi | ControlLogix Standart AC Quvvat Manbai, Konformal Qoplangan |
| Ilova | Qattiq muhitlarda ControlLogix korpusi va modullariga quvvat ta'minlaydi |
| Moslik | 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17 (A, B, C seriyalari) bilan mos |
| Funktsiya | Korpus orqa paneliga DC quvvat ta'minlaydi |
Funktsional spetsifikatsiyalar
| Parametr | Ma'lumotlar |
|---|---|
| Kirish kuchlanishi oralig‘i | 85_265 V AC |
| Nominal kirish kuchlanishi | 120 V/240 V AC |
| Kirish chastotasi | 47_63 Hz |
| Kirish quvvati | 100 VA maksimal |
| Maksimal chiqish quvvati | 75 W @ 0_60°C (32_140°F) |
| Yuklanish oqimi | 20 A maksimal |
| Joriy sig‘imi | 4 A @ 3.3 V DC, 10 A @ 5.1 V DC, 2.8 A @ 24 V DC |
| Saqlash vaqti | 5 sikl @ 85 V AC, 6 sikl @ 120 V AC, 6 sikl @ 200 V AC, 6 sikl @ 240 V AC (50/60 Hz) |
| Izolyatsiya kuchlanishi | 250 V (uzluksiz), Mustahkamlangan izolyatsiya turi, 3500 V DC da 60 s sinovdan o‘tgan |
| Quvvat yo‘qotilishi | 85.3 BTU/soat |
| Terminal ulanishlari | Korpusning eng chap joyi |
| Sim o‘lchami | 2.5 mm² (14 AWG) qattiq yoki tolali mis sim, 90°C yoki undan yuqori haroratga mo‘ljallangan |
| Ishlash harorati | 0°C dan 60°C gacha (32°F dan 140°F gacha) |
| Saqlash harorati | -40°C dan 85°C gacha (-40°F dan 185°F gacha) |
| Namlik | 5% dan 95% gacha (kondensatsiyasiz) |
| Vibratsiyaga chidamlilik | 2 G @ 10_500 Hz |
| Urish chidamliligi | 30 G (ishlashda), 50 G (ishlamayotganda) |
| O‘lchamlari | 14.0 x 11.2 x 14.5 sm (5.51 x 4.41 x 5.71 dyuym) |
| Og‘irligi | 0.95 kg (2.10 funt) |
| Standartlarga muvofiqlik | CE, UL, CSA (I sinf, 2-bo‘lim, A, B, C, D guruhlari), FM |
