| Processor |
Intel Atom Dual Core CPU |
| Operating System |
Linux 32-bit (Debian 8.9) |
| Storage |
32 GB Solid State Drive (SSD) |
| Memory |
Not specified (dependent on application) |
| Communication Ports |
2 Gigabit Ethernet (GbE) ports, 1 USB 3.0 device port, 1 DisplayPort |
| Display Support |
High-definition monitor connectivity via DisplayPort |
| Backplane Current Load |
1.2 A @ 5.1 V DC, 3 mA @ 24 V DC |
| Power Dissipation |
6.5 W maximum |
| Isolation |
30 V (continuous), basic insulation type (between Ethernet/USB/DisplayPort and backplane) |
| Terminal Connections |
None (uses backplane, Ethernet, USB, or DisplayPort for connectivity) |
| Wire Size |
Not applicable (no field wiring) |
| Operating Temperature |
-25°C to 60°C (-13°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Humidity |
5% to 95% (non-condensing) |
| Vibration Tolerance |
2 G @ 10–500 Hz |
| Shock Tolerance |
30 G (operating), 50 G (non-operating) |
| Dimensions |
145 mm x 35 mm x 140 mm (5.71 in x 1.38 in x 5.51 in) |
| Weight |
0.4 kg (0.88 lb) |
| Standards Compliance |
CE, UL, CSA (Class I, Div 2, Groups A, B, C, D), RoHS |
| Certifications |
TUV certified for functional safety (up to SIL 2, depending on application) |
