GE IC200CHS003K
GE IC200CHS003K
Manufacturer: General Electric
Product No.: IC200CHS003K
Condition:1000 na skladištu
Product Type: VersaMax Connector-Style I/O Carrier
Product Origin: USA
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- Podrška 24/7
- Povraćaj u roku od 30 dana
- Brza dostava
Product Overview
| Parameter | Details |
|---|---|
| Part Number | IC200CHS003K |
| Product Name | VersaMax Connector-Style I/O Carrier |
| Application | Provides mounting, backplane communications, and field wiring for single I/O modules in industrial automation and process control systems |
| Compatibility | VersaMax PLC system; compatible with all VersaMax I/O modules except high-isolation modules (IC200MDL144, IC200MDL244, IC200MDD850) |
| Function | Connectorized carrier for easy cable connection, supporting up to 32 I/O points with hot insertion capability |
Functional Specifications
| Parameter | Details |
|---|---|
| Module Capacity | Supports 1 I/O module |
| Terminal Type | 36-pin connector for I/O cable attachment |
| Current Rating | Up to 2 A per point; 8 A per power and ground |
| Voltage Rating | Up to 264 V AC |
| Mounting | DIN-rail or panel mount |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to +85°C |
| Protection Rating | IP20 |
| Dimensions | Standard VersaMax carrier size (approximate: 90 mm x 50 mm x 75 mm) |
| Weight | Approximately 0.2 kg |
| Certifications | CE marked; UL, cUL, CSA compliant |
| Standards Compliance | IEC 61131-2 compliant for programmable controllers |
Ordering Information
| Parameter | Details |
|---|---|
| Part Number Configuration | IC200CHS003K (Connector-style carrier, Revision K) |
| Available Options | Connector kit IC200ACC304 for custom cables; compatible with VersaMax expansion systems |
| Customization | Extended temperature range or hazardous area certifications available upon request |
Product Description
Product Overview
| Parameter | Details |
|---|---|
| Part Number | IC200CHS003K |
| Product Name | VersaMax Connector-Style I/O Carrier |
| Application | Provides mounting, backplane communications, and field wiring for single I/O modules in industrial automation and process control systems |
| Compatibility | VersaMax PLC system; compatible with all VersaMax I/O modules except high-isolation modules (IC200MDL144, IC200MDL244, IC200MDD850) |
| Function | Connectorized carrier for easy cable connection, supporting up to 32 I/O points with hot insertion capability |
Functional Specifications
| Parameter | Details |
|---|---|
| Module Capacity | Supports 1 I/O module |
| Terminal Type | 36-pin connector for I/O cable attachment |
| Current Rating | Up to 2 A per point; 8 A per power and ground |
| Voltage Rating | Up to 264 V AC |
| Mounting | DIN-rail or panel mount |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to +85°C |
| Protection Rating | IP20 |
| Dimensions | Standard VersaMax carrier size (approximate: 90 mm x 50 mm x 75 mm) |
| Weight | Approximately 0.2 kg |
| Certifications | CE marked; UL, cUL, CSA compliant |
| Standards Compliance | IEC 61131-2 compliant for programmable controllers |
Ordering Information
| Parameter | Details |
|---|---|
| Part Number Configuration | IC200CHS003K (Connector-style carrier, Revision K) |
| Available Options | Connector kit IC200ACC304 for custom cables; compatible with VersaMax expansion systems |
| Customization | Extended temperature range or hazardous area certifications available upon request |
