Manufacturer: General Electric
Product No.: IC200ACC415
Condition:В наличии: 1000
Product Type: VersaMax 36-Point Spring-Clamp Terminal Block with Shielded Cable Support
Product Origin: USA
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- Круглосуточная поддержка
- Возврат в течение 30 дней
- Быстрая доставка
Product Details
| Parameter | Details |
|---|---|
| Manufacturer | General Electric |
| Model/Part Number | IC200ACC415 |
| Description | VersaMax 36-Point Spring-Clamp Terminal Block with Shielded Cable Support |
Product Overview
| Parameter | Details |
|---|---|
| Part Number | IC200ACC415 |
| Product Name | IC200ACC415 36-Point Spring-Clamp Terminal Block with Shield Grounding |
| Application | High-density field wiring for VersaMax 32/36-point I/O modules in noisy electrical environments requiring shielded cables (e.g., analog, high-speed digital, or long cable runs) |
| Compatibility | Designed for GE VersaMax high-density I/O modules (e.g., IC200MDL329, IC200MDL330, IC200MDDxxx); mounts directly onto the front of compatible modules |
| Function | Provides 36 spring-clamp terminals with integrated shield grounding bar and drain wire termination; enables tool-free wiring and proper EMI/RFI shielding for improved signal integrity |
Functional Specifications
| Parameter | Details |
|---|---|
| Type | 36-point spring-clamp interposing terminal block with shield grounding |
| Terminal Count | 36 spring-clamp terminals (18 per side) + 2 dedicated shield/drain terminals |
| Wire Size | 14_26 AWG (2.1_0.14 mm²), solid or stranded (ferruled recommended) |
| Shield/Drain Wire | Accepts up to 16 AWG drain wire; spring-clamp or screw clamp option |
| Strip Length | 6_7 mm |
| Current Rating | 2 A per point, 8 A per common (maximum) |
| Voltage Rating | 150 V AC/DC maximum |
| Connection Method | Spring-clamp cage with push-in actuator; 40-pin plug-in connector mates with I/O module header |
| Shield Grounding | Integrated grounding bar connects all shield terminals to chassis via mounting screw or optional ground strap |
| Insertion Force | < 50 N per wire |
| Retention Force | > 35 N per wire |
| Tool-Free Wiring | Yes _ actuator lever or flat-blade screwdriver |
| Labeling | Pre-marked terminal numbers (1_36); SHIELD labels; accepts adhesive strips |
| Mounting | Snaps directly onto front of compatible 32/36-point VersaMax I/O modules |
| Hot Swap Support | Allows terminal block removal/replacement without system power-down |
| LED Visibility | Open design preserves full view of module status LEDs |
| EMI/RFI Protection | Shield continuity maintained through grounding bar; reduces noise coupling |
| Operating Temperature Range | -40°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Vibration | IEC 60068-2-6 (5g, 10_150 Hz) |
| Shock | IEC 60068-2-27 (30g, 11 ms) |
| Dimensions | 4.33" x 1.10" x 2.17" (110 mm x 28 mm x 55 mm) approximate _ slightly taller than IC200ACC414 for shield bar |
| Weight | 0.20 lb (0.09 kg) |
| Enclosure Rating | IP20 (finger-safe) |
| Standards Compliance | IEC 61131-2, CE, UL, CSA, Class I Division 2, ATEX Zone 2, RoHS 2 (2011/65/EU), EN 61984, IEC 61000-4-4/5/6 (EMI immunity) |
