Siemens 6DD1640-0AH0
Siemens 6DD1640-0AH0
Manufacturer: Siemens
Product No.: 6DD1640-0AH0
Condition:Қорда 1000 бар
Product Type: SIMATIC TDC Signal Module SM500
Product Origin: Germany
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Қолдау
- 30 Күндік Қайтарулар
- Жылдам жеткізу
Product Details
| Parameter | Details |
|---|---|
| Manufacturer | Siemens |
| Model/Part Number | 6DD1640-0AH0 |
| Description | SIMATIC TDC Signal Module SM500 |
Product Overview
| Parameter | Details |
|---|---|
| Part Number | 6DD1640-0AH0 |
| Product Name | SIMATIC TDC Signal Module SM500 |
| Application | Signal conditioning and I/O interfacing in industrial automation and process control applications |
| Compatibility | Integrates with Siemens SIMATIC TDC and SIMADYN D systems; supports backplane bus communication |
| Function | Provides analog and digital I/O with encoder inputs for motion control and process monitoring |
Functional Specifications
| Parameter | Details |
|---|---|
| Type | Signal module with mixed I/O |
| Analog Outputs (AO) | 8 channels (voltage or current configurable) |
| Analog Inputs (AI) | 8 channels (voltage or current configurable) |
| Digital Outputs (DO) | 16 channels (24 V DC) |
| Digital Inputs (DI) | 16 channels (24 V DC) |
| Incremental Encoder Inputs | 4 channels (differential, up to 1 MHz) |
| Absolute Encoder Inputs | 4 channels (SSI, EnDat, Hiperface compatible) |
| LED Indicators | 6 status LEDs for module and channel diagnostics |
| Power Supply | 24 V DC nominal |
| Power Consumption | 5.5 W maximum |
| Operating Temperature Range | 0 to 60°C |
| Dimensions | 40 mm x 125 mm x 117 mm (W x H x D) |
| Weight | 0.56 kg |
| Mounting | DIN rail or rack mount in control cabinet |
| Isolation | Galvanic isolation between channels and backplane |
| Standards Compliance | IEC 61131-2, CE, UL, CSA |
