| Input Voltage |
85_132 V AC / 170_264 V AC (auto-select via jumper) |
| Input Frequency |
47_63 Hz |
| Input Current |
1.4 A @ 120 V, 0.8 A @ 230 V |
| Inrush Current |
_ 30 A @ 264 V (cold start) |
| Output Voltage |
24 V DC ±3% (23.28_24.72 V) |
| Output Current |
0_5 A (continuous), 6 A peak (< 1 min) |
| Output Power |
120 W |
| Ripple/Noise |
_ 150 mVpp (20 MHz bandwidth) |
| Efficiency |
_ 85% @ full load |
| Hold-Up Time |
_ 20 ms @ 120 V, _ 150 ms @ 230 V |
| Overload Protection |
Electronic current limit @ 5.5_6.5 A, auto-recovery
|
| Short-Circuit Protection |
Yes _ constant current, hiccup mode
|
| Parallel Operation |
Yes _ up to 2 units (with 6ES7307-1KA02-0AA0 load-sharing module) |
| Redundancy |
Yes _ with 6ES7307-1KA02-0AA0 or SITOP RED1200
|
| Isolation |
3000 V AC input-to-output, 1500 V AC input-to-ground |
| EMC |
EN 61000-6-2 (immunity), EN 61000-6-4 (emission), Class B
|
| Diagnostic LED |
Green: Output OK Red flashing: Overload/short-circuit |
| Output Terminal |
L+ / M (screw terminals, 0.5_4 mm²) |
| Input Terminal |
L / N / PE (screw terminals, 0.5_2.5 mm²) |
| Power Supply to Backplane |
Direct via S7-300 backplane bus
|
| Power Loss |
18 W @ full load |
| Operating Temperature Range |
0°C to +60°C (derating >50°C: 2%/K) |
| Storage Temperature Range |
-40°C to +85°C |
| Humidity |
5% to 95% non-condensing |
| Vibration |
IEC 60068-2-6 (2g, 10_150 Hz) |
| Shock |
IEC 60068-2-27 (15g, 11 ms) |
| Mounting |
35 mm DIN rail or S7-300 rack (leftmost slot) |
| Dimensions (W x H x D) |
80 mm _ 125 mm _ 120 mm |
| Weight |
0.8 kg |
| Enclosure Rating |
IP20 |
| Certifications |
CE, UL, cUL, FM Class I Div 2, ATEX Zone 2, China RoHS, EAC, KC
|
