Siemens 6ES7193-6BP20-0DA0
Siemens 6ES7193-6BP20-0DA0
Manufacturer: Siemens
Product No.: 6ES7193-6BP20-0DA0
Condition:1000 במלאי
Product Type: SIMATIC ET 200SP BaseUnit BU15-P16+A10+2D
Product Origin: Germany
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- תמיכה 24/7
- החזרות תוך 30 יום
- משלוח מהיר
Product Overview
| Parameter | Details |
|---|---|
| Part Number | 6ES7193-6BP20-0DA0 |
| Product Name | SIMATIC ET 200SP BaseUnit BU15-P16+A10+2D |
| Application | Modular base unit for mounting ET 200SP I/O modules in distributed I/O systems for industrial automation and process control |
| Compatibility | SIMATIC ET 200SP series; supports 15 mm wide electronic modules with push-in terminals |
| Function | Provides mechanical mounting, field wiring termination, and power distribution via AUX terminals and new load group |
Functional Specifications
| Parameter | Details |
|---|---|
| BaseUnit Type | BU Type A0 |
| Terminal Type | Push-in terminals |
| Number of Terminals | 16 process terminals (P1-P16) + 10 AUX terminals |
| Wire Cross-Section | 0.14 mm² to 1.5 mm² (AWG 26 to 16) |
| Stripping Length | 8 mm to 10 mm |
| Current Rating | 2 A per process terminal; 10 A total for P1/P2 and AUX rails |
| Voltage Rating | 24 V DC (18 V to 30 V permissible) |
| Load Group | New load group for electrical isolation |
| AUX Bus | Continuous AUX1 connection for power supply |
| Operating Temperature | 0°C to 60°C (horizontal); 0°C to 50°C (vertical) |
| Storage Temperature | -40°C to +70°C |
| Protection Rating | IP20 |
| Dimensions | 15 mm (W) x 141 mm (H) x 58 mm (D) |
| Weight | Approximately 0.045 kg |
| Certifications | CE, UL, cUL, CSA, ATEX Zone 2, IECEx |
| Standards Compliance | IEC 61131-2 compliant for programmable controllers |
Ordering Information
| Parameter | Details |
|---|---|
| Part Number Configuration | 6ES7193-6BP20-0DA0 (BU15-P16+A10+2D, push-in terminals, 10 AUX terminals, new load group) |
| Available Options | Variants for screw terminals (e.g., 6ES7193-4CB20-0AA0); packs of 5 available |
| Customization | Extended temperature range or hazardous area certifications available upon request |
