Siemens 6ES7193-6BP00-0DA0
Siemens 6ES7193-6BP00-0DA0
Manufacturer: Siemens
Product No.: 6ES7193-6BP00-0DA0
Condition:1000 במלאי
Product Type: SIMATIC ET 200SP BaseUnit BU15-P16+A0+2D
Product Origin: Germany
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- תמיכה 24/7
- החזרות תוך 30 יום
- משלוח מהיר
Product Overview
| Parameter | Details |
|---|---|
| Part Number | 6ES7193-6BP00-0DA0 |
| Product Name | SIMATIC ET 200SP BaseUnit BU15-P16+A0+2D |
| Application | Distributed I/O systems for industrial automation and process control, providing base mounting for electronic modules |
| Compatibility | SIMATIC ET 200SP series; supports 15 mm wide electronic modules with push-in terminals |
| Function | Base unit for secure module mounting and wiring, with new load group and AUX1 terminals for power distribution |
Functional Specifications
| Parameter | Details |
|---|---|
| Base Unit Type | BU type A0 |
| Terminal Type | Push-in terminals (without auxiliary terminals) |
| Width x Height | 15 mm x 117 mm |
| Load Group | New load group (supports up to 10 A at 24 V DC) |
| Mounting | DIN rail (35 mm) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to +70°C |
| Protection Rating | IP20 |
| Dimensions | 15 mm (W) x 117 mm (H) x 58 mm (D) |
| Weight | Approximately 0.05 kg |
| Certifications | CE marked; UL, cUL, CSA compliant |
| Standards Compliance | IEC 61131-2 compliant for programmable controllers |
Ordering Information
| Parameter | Details |
|---|---|
| Part Number Configuration | 6ES7193-6BP00-0DA0 (BU15-P16+A0+2D, push-in terminals, new load group) |
| Available Options | Variants for screw terminals (e.g., 6ES7193-4CB00-0AA0); packs of 5 |
| Customization | Extended temperature range or hazardous area certifications available upon request |
