Siemens 6ES7231-5PD32-0XB0

Siemens 6ES7231-5PD32-0XB0

  • Manufacturer: Siemens

  • Product No.: 6ES7231-5PD32-0XB0

  • Condition:1000 en stock

  • Product Type: SIMATIC S7-1200 Analog Input SM 1231 RTD 4xAI RTD module

  • Product Origin: Germany

  • Payment: T/T, Western Union

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • Assistance 24h/24 et 7j/7
  • Retours sous 30 jours
  • Expédition rapide

Product Details



Parameter Details
Manufacturer Siemens
Model/Part Number 6ES7231-5PD32-0XB0
Description SIMATIC S7-1200 Analog Input SM 1231 RTD 4xAI RTD module

Product Overview



Parameter Details
Part Number 6ES7231-5PD32-0XB0
Product Name SM 1231 RTD 4xAI RTD Module
Application Analog input expansion for S7-1200 PLCs in industrial automation and process control
Compatibility SIMATIC S7-1200 CPUs; mounts on right-side expansion rail
Function Provides 4 RTD inputs for precise temperature measurement from sensors

Functional Specifications



Parameter Details
Input Channels 4 analog inputs
Input Type Resistance thermometer (RTD)
RTD Types Supported Pt100, Pt1000, Ni120, Ni1000 (IEC 60751, JIS C 1604)
Temperature Range -200 to +850°C (depends on RTD type)
Resolution 15 bit
Accuracy 0.05% of full scale
Update Rate Synchronized with CPU scan cycle
Isolation 500 V AC (input to logic)
Cable Length Up to 1000 m (shielded twisted pair)
Power Supply 20.4-28.8 V DC from PLC backplane
Power Consumption 40 mA at 5 V DC, 10 mA at 24 V DC
Operating Temperature Range -20 to +60°C
Dimensions 100 mm x 45 mm x 75 mm (H x W x D)
Weight 0.18 kg
Mounting Snap-on to S7-1200 DIN rail
Protection Rating IP20
Standards Compliance IEC 61131-2, CE, UL, CSA
Voir tous les détails

Product Description

Product Details



Parameter Details
Manufacturer Siemens
Model/Part Number 6ES7231-5PD32-0XB0
Description SIMATIC S7-1200 Analog Input SM 1231 RTD 4xAI RTD module

Product Overview



Parameter Details
Part Number 6ES7231-5PD32-0XB0
Product Name SM 1231 RTD 4xAI RTD Module
Application Analog input expansion for S7-1200 PLCs in industrial automation and process control
Compatibility SIMATIC S7-1200 CPUs; mounts on right-side expansion rail
Function Provides 4 RTD inputs for precise temperature measurement from sensors

Functional Specifications



Parameter Details
Input Channels 4 analog inputs
Input Type Resistance thermometer (RTD)
RTD Types Supported Pt100, Pt1000, Ni120, Ni1000 (IEC 60751, JIS C 1604)
Temperature Range -200 to +850°C (depends on RTD type)
Resolution 15 bit
Accuracy 0.05% of full scale
Update Rate Synchronized with CPU scan cycle
Isolation 500 V AC (input to logic)
Cable Length Up to 1000 m (shielded twisted pair)
Power Supply 20.4-28.8 V DC from PLC backplane
Power Consumption 40 mA at 5 V DC, 10 mA at 24 V DC
Operating Temperature Range -20 to +60°C
Dimensions 100 mm x 45 mm x 75 mm (H x W x D)
Weight 0.18 kg
Mounting Snap-on to S7-1200 DIN rail
Protection Rating IP20
Standards Compliance IEC 61131-2, CE, UL, CSA
