زیمنس 6ES7193-4CA40-0AA0
زیمنس 6ES7193-4CA40-0AA0
Manufacturer: Siemens
Product No.: 6ES7193-4CA40-0AA0
Condition:1000 در انبار
Product Type: SIMATIC DP Terminal Module TM-P15C23-A1
Product Origin: Germany
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- پشتیبانی 24/7
- بازگشت 30 روزه
- حمل و نقل سریع
Product Details
| Parameter | Details |
|---|---|
| Manufacturer | Siemens |
| Model/Part Number | 6ES7193-4CA40-0AA0 |
| Description | SIMATIC DP Terminal Module TM-P15C23-A1 |
Product Overview
| Parameter | Details |
|---|---|
| Part Number | 6ES7193-4CA40-0AA0 |
| Product Name | TM-P15C23-A1 Terminal Module for ET 200S |
| Application | Field wiring termination for ET 200S distributed I/O in industrial automation, machine building, and process control |
| Compatibility | - ET 200S I/O modules (digital/analog) - PROFIBUS DP and PROFINET via IM 151 - Supports hot swap and electronic modules |
| Function | Provides 15 screw-type terminals with push-in cage clamp for fast, reliable, tool-free field wiring; includes shielding and diagnostics support |
Functional Specifications
| Parameter | Details |
|---|---|
| Type | Passive terminal module (TM-P) |
| Terminals | 15 screw-type with push-in cage clamp |
| Terminal Layout | - 1_15: Signal terminals - PE: Protective earth - SH: Shield connection |
| Wire Size | 0.14_1.5 mm² (26_16 AWG) solid/stranded |
| Strip Length | 8 mm |
| Terminal Torque | 0.4_0.5 Nm |
| Rated Current | 2 A per terminal |
| Rated Voltage | 24 V DC / 230 V AC |
| Shielding | Integrated shield bar with spring contact |
| Hot Swap | Yes _ supports live module replacement |
| Diagnostics | LED per terminal (via compatible I/O module) |
| Labeling | Integrated label holder (6ES7193-4GA00-0AA0) |
| Color | Light gray (RAL 7035) |
| Mounting | Snaps onto ET 200S base unit (BU15-P16+A0+2D) |
Electrical Specifications
| Parameter | Details |
|---|---|
| Power Supply | None (passive) _ powered via I/O module |
| Isolation | 500 V AC (field to backplane via I/O module) |
| Grounding | PE terminal connected to DIN rail |
Mechanical Specifications
| Parameter | Details |
|---|---|
| Dimensions (W x H x D) | 15 mm _ 119 mm _ 75 mm |
| Weight | 0.07 kg |
| Housing Material | Polyamide (PA 6.6), halogen-free |
| Terminal Cover | Hinged, transparent, with label pocket |
Environmental Specifications
| Parameter | Details |
|---|---|
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +70°C |
| Humidity | 5_95% non-condensing |
| Vibration | 5g (IEC 60068-2-6) |
| Shock | 15g (IEC 60068-2-27) |
| Enclosure Rating | IP20 |
Key Features
| Feature | Benefit |
|---|---|
| Push-in Cage Clamp | Tool-free, vibration-resistant wiring |
| 15 mm Width | High density (up to 64 I/O per meter) |
| Integrated Shield | EMC-compliant grounding |
| Hot Swap | Zero downtime maintenance |
| Label Holder | Clear terminal identification |
