| Type |
Single-slot I/O carrier base |
| Mounting |
35 mm DIN rail (EN 50022) |
| Module Support |
1 VersaMax I/O module per carrier |
| Backplane Power |
+5 V DC and +24 V DC supplied via adjacent carrier or power booster |
| Field Wiring |
Screw-type terminal block, 14_22 AWG (2.5_0.34 mm²), 18 terminals (9 per side) |
| Terminal Torque |
0.5 Nm (4.4 in-lb) maximum |
| Hot Swap |
Supports live insertion/removal of I/O modules without system power-down |
| Power Pass-Through |
Daisy-chain power to adjacent carriers via integrated bus bars |
| LED Indicators |
None (module-specific LEDs on I/O module) |
| Isolation |
Field terminals isolated from backplane logic |
| Operating Temperature Range |
-40°C to +60°C |
| Storage Temperature Range |
-40°C to +85°C |
| Humidity |
5% to 95% non-condensing |
| Vibration |
IEC 60068-2-6 (5g, 10_150 Hz) |
| Shock |
IEC 60068-2-27 (30g, 11 ms) |
| Dimensions |
4.33" x 2.68" x 1.77" (110 mm x 68 mm x 45 mm) approximate |
| Weight |
0.22 lb (0.1 kg) |
| Enclosure Rating |
IP20 (finger-safe terminals with cover) |
| Standards Compliance |
IEC 61131-2, CE, UL, CSA, Class I Division 2, ATEX Zone 2, RoHS compliant |
