Siemens 6ES7195-1GG30-0XA0
Siemens 6ES7195-1GG30-0XA0
Manufacturer: Siemens
Product No.: 6ES7195-1GG30-0XA0
Condition:1000 в наличност
Product Type: SIMATIC DP Mounting Rail for ET 200M _ 530 mm
Product Origin: Germany
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- Поддръжка 24/7
- 30-дневни връщания
- Бърза доставка
Product Overview
| Parameter | Details |
|---|---|
| Part Number | 6ES7195-1GG30-0XA0 |
| Product Name | SIMATIC DP Mounting Rail for ET 200M _ 530 mm (with grounding) |
| Application | Mechanical mounting base for ET 200M distributed I/O modules in control cabinets and machine panels |
| Compatibility | SIMATIC ET 200M (IM 153-1/2, digital/analog modules); S7-300/400, PCS7, TIA Portal |
| Function | Provides DIN-rail mounting, integrated PE (protective earth) rail, bus module support, and removal/insertion under power |
Functional Specifications
| Parameter | Details |
|---|---|
| Length | 530 mm (standard S7-300 rack width) |
| Material | Steel, zinc-plated with integrated PE conductor rail |
| Mounting Type | 35 mm DIN rail (EN 60715) _ snap-on or screw mounting |
| Module Slots | Supports up to 12 bus modules (IM 153 + 11 I/O) |
| Grounding | Integrated PE rail _ direct connection via grounding terminals |
| Load Capacity | _ 10 kg distributed (module + wiring) |
| Bus Module Support | 6ES7195-7HB00-0XA0 (active bus module) _ hot-swap capable |
| Operating Temperature | 0°C to +60°C (horizontal); 0°C to +50°C (vertical) |
| Storage Temperature | _40°C to +70°C |
| Protection Rating | IP00 (open frame _ for use in enclosures) |
| Dimensions (L_W_H) | 530 mm _ 35 mm _ 7.5 mm |
| Weight | _ 0.65 kg |
| Certifications | CE, UL, cUL, CSA, ATEX Zone 2, IECEx |
| Standards Compliance | IEC 60715 (DIN rail), IEC 61131-2, EN 61000-6-2/4 (EMC) |
Ordering Information
| Parameter | Details |
|---|---|
| Part Number Configuration | 6ES7195-1GG30-0XA0 (GG = 530 mm; 30 = with PE rail) |
| Replaces / Supersedes | 6ES7195-1GC00-0XA0 (adds integrated PE rail, improved grounding) |
| Available Options | _ 6ES7195-1GF30-0XA0: 483 mm (S7-300 standard) _ 6ES7195-1GA00-0XA0: 483 mm (basic) _ 6ES7195-1BE00-0XA0: 160 mm (short) |
| Pack Size | 1 unit |
| Required Accessories | _ 6ES7195-7HB00-0XA0: Active bus module (for hot-swap) _ 6ES7390-1AB60-0AA0: Grounding terminal _ 6ES7392-1AJ00-0AA0: Labeling strips |
| Compatible Modules | _ 6ES7131/7132/7134/7135: Digital/analog I/O _ 6ES7153-2BAxx-0XB0: IM 153-2 PROFINET |
Key Upgrade & Compatibility Notes
| Feature | Benefit / Upgrade Path |
|---|---|
| Integrated PE Rail | Direct grounding _ no external jumpers; improved EMC |
| 530 mm Length | Full S7-300 rack compatibility _ fits standard 19" subracks |
| Hot-Swap Ready | With 6ES7195-7HB00-0XA0 _ replace I/O modules under power |
| Backward Compatible | Drop-in replacement for older 6ES7195-1GCxx rails |
| TIA Portal Ready | Full support in TIA Portal V15+, Step7, PCS7 |
| Robust Design | Zinc-plated steel _ ideal for vibration, corrosive environments |
