GE IC200ALG266
GE IC200ALG266
Manufacturer: General Electric
Product No.: IC200ALG266
Condition:1000 в наличност
Product Type: VersaMax 15-Channel Analog Input Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- Поддръжка 24/7
- 30-дневни връщания
- Бърза доставка
Product Overview
| Parameter | Details |
|---|---|
| Part Number | IC200ALG266 |
| Product Name | VersaMax 15-Channel Analog Input Module |
| Application | Analog signal acquisition for industrial automation and process control systems, suitable for monitoring process variables like pressure, flow, level, and temperature |
| Compatibility | VersaMax PLC system; integrates with VersaMax CPUs, power supplies, NIUs, and carriers via backplane |
| Function | Provides 15 single-ended analog inputs with high resolution for precise data collection and fault diagnostics |
Functional Specifications
| Parameter | Details |
|---|---|
| Number of Channels | 15 (single-ended, one group) |
| Input Type | Voltage inputs (-10 V to +10 V DC) |
| Resolution | 15-bit |
| Accuracy | ±0.3% typical of full scale; ±0.5% maximum of full scale at 25°C; ±1% maximum at 0-60°C |
| Update Rate | 7.5 ms per channel (112.5 ms full scan) |
| Supply Voltage | Backplane-powered (5 V DC, 150 mA max) |
| Operating Temperature | -40°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Protection Rating | IP20 |
| Isolation | None (non-isolated) |
| Dimensions | Standard VersaMax module size (approximate: 90 mm x 50 mm x 75 mm) |
| Weight | Approximately 0.2 kg |
| Certifications | CE marked; TUV approved; UL, cUL, CSA compliant |
| Standards Compliance | IEC 61131-2 compliant for programmable controllers; SIL 2 rated |
Ordering Information
| Parameter | Details |
|---|---|
| Part Number Configuration | IC200ALG266 (15-channel, 15-bit voltage input module, TUV approved) |
| Available Options | Variants for current inputs (e.g., IC200ALG264) or HART-enabled versions |
| Customization | Fieldbus integration or extended temperature range available upon request |
Product Description
