Product Description
Product Details
| Parameter | Details |
|---|---|
| Manufacturer | General Electric |
| Model/Part Number | DS2020DACAG2 |
| Description | Analog Output Module |
Product Overview
| Parameter | Details |
|---|---|
| Part Number | DS2020DACAG2 |
| Product Name | DS2020DACAG2 Analog Output Board |
| Application | Analog signal output in turbine control systems for power generation and industrial applications |
| Compatibility | Designed for GE Mark V and Mark VI turbine control systems; interfaces with I/O modules and field wiring |
| Function | Provides high-accuracy analog output processing for voltage or current signals with diagnostics and redundancy support |
Functional Specifications
| Parameter | Details |
|---|---|
| Output Channels | 8 isolated channels |
| Output Types | Voltage: 0-10 V; Current: 4-20 mA |
| Resolution | 16-bit D/A conversion |
| Accuracy | ±0.1% of span typical |
| Isolation | Channel-to-channel and channel-to-bus isolation (1500 V) |
| Load Resistance | Up to 750 Ω for current outputs |
| Power Supply | 28 V DC nominal (from system backplane) |
| Power Consumption | 2 W maximum |
| Operating Temperature Range | -30°C to +70°C |
| Mounting | Rack mount in control cabinet |
| Dimensions | 10.5" x 8.5" x 1.5" (267 mm x 216 mm x 38 mm) approximate |
| Weight | 2.5 lb (1.13 kg) |
| Standards Compliance | IEC 61131-2, CE, UL, CSA |
