Product Description
Product Details
| Parameter | Details |
|---|---|
| Manufacturer | General Electric |
| Model/Part Number | DS200TCDAG1BCB |
| Description | Terminal Control and Diagnostics Board |
Product Overview
| Parameter | Details |
|---|---|
| Part Number | DS200TCDAG1BCB |
| Product Name | DS200TCDAG1B Terminal Control Board |
| Application | Terminal control and diagnostics in turbine control systems for power generation |
| Compatibility | Designed for GE Speedtronic Mark V turbine control systems; interfaces with I/O modules and control processors |
| Function | Manages terminal communications, diagnostics, and supports signal routing for control and monitoring |
Functional Specifications
| Parameter | Details |
|---|---|
| Type | Terminal control and diagnostics board with analog/digital interfaces |
| Signal Processing | Supports serial communication, digital I/O up to 24 V DC |
| Communication | RS-232/RS-485 serial ports for terminal connections |
| Power Supply | 24 V DC nominal (from system backplane) |
| Power Consumption | 5 W maximum |
| Operating Temperature Range | -30°C to +70°C |
| Mounting | Rack mount in control cabinet |
| Dimensions | 10.5" x 8.5" x 1.5" (267 mm x 216 mm x 38 mm) approximate |
| Weight | 2.5 lb (1.13 kg) |
| Protection Features | Overvoltage protection, EMI shielding |
| Standards Compliance | IEC 61131-2, CE, UL, CSA |
